Toshiba Tosvert VF-AS1 User Manual
Page 261
K-23
E6581301
11
[24] Protection functions [2/3]
Vector control
Title
Communi
cation
No.
Function
Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H
0613
Selection of short circuit
detection at starting
0:Each time (standard pulse)
1:Only one time after power is turned on
2:Each time (short pulse)
3.Only one time after power is turn on (short pulse)
1/1
0
Disabled
●/●
●/●
●
●
6. 33. 9
H
0615
Overtorque trip selection
0:No trip, 1:Trip
1/1
0
Enabled
●/●
●/●
●
●
6. 33. 10
H
0616
Overtorque detection level
during power running
0~250%
1/0.01
150
Enabled
●/●
●/●
●
●
6. 33. 10
H
0617
Overtorque detection level
during regenerative braking
0~250%
1/0.01
150
Enabled
●/●
●/●
●
●
6. 33. 10
H
0618
Overtorque detection time
0.00~10.00 sec.
0.01/0.01
0.50
Enabled
●/●
●/●
●
●
6. 33. 10
H
0619
Overtorque detection hysteresis 0~100%
1/0.01
10
Enabled
●/●
●/●
●
●
6. 33. 10
H
0620
Cooling fan control selection
0:Auto, 1:Always ON
1/1
0
Enabled
●/●
●/●
●
●
6. 33. 11
H
0621
Cumulative operation time alarm
setting
0.1~999.9 (x100h)
0.1/0.1
610.0
Enabled
●/●
●/●
●
●
6. 33. 12
H
0622
Abnormal speed detection time
0.01~100.0 sec.
0.01/0.01
0.01
Enabled
-/●
-/-
-
-
6. 33. 13
H
0623
Overspeed detection frequency
upper band
0.0:Disabled, 0.1~30.0Hz
0.1/0.01
0.0
Enabled
-/●
-/-
-
-
6. 33. 13
H
0624
Overspeed detection frequency
lower band
0.0:Disabled, 0.1~30.0Hz
0.1/0.01
0.0
Enabled
-/●
-/-
-
-
6. 33. 13
H
0625
Undervoltage detection level
50~79%, 80: (auto mode)
1/1
80
Disabled
●/●
●/●
●
●
6. 33. 15
H
0626
Overvoltage limit operation level 100~150%
1/1
134
Disabled
●/●
-
●
●
6. 14. 2
H
0627
Undervoltage trip selection
0:Deselect, 1:Select
1/1
0
Disabled
●/●
●/●
●
●
6. 33. 15
H
0628
Undervoltage (trip alarm)
detection time
0.01~10.00 sec.
0.01/0.01
0.03
Disabled
●/●
●/●
●
●
6. 33. 15
H
0629
Regenerative power ride-through
control level
55~100%
1/1
75
Disabled
●/●
●/●
●
●
6. 33. 16
H
0630
Braking answer waiting time
0.0:Disabled, 0.1~10.0 sec.
0.1/0.1
0.0
Enabled
●/●
●/●
●
●
6. 33. 17
H
0631
Inverter overload selection
0:Standard (150%-60 sec.)
1:Estimation of temperature
1/1
0
Disabled
-
-
-
-
5. 14
H
0633
VI/II analog input wire breakage
detection level
0:None
1~100%
1/1
0
Enabled
●/●
●/●
●
●
6. 33. 18
H
0634
Annual average ambient
temperature (calculation for part
replacement alarms)
1:-10~+10°C
2:+11~+20°C
3:+21~+30°C
4:+31~+40°C
5:+41~+50°C
6:+51~+60°C
1/1
3
Enabled
●/●
●/●
●
●
6. 33. 19
H
0635
Rush current suppression relay
activation time
0.0~2.5 sec.
0.1/0.1
0.0
Disabled
●/●
●/●
●
●
6. 33. 20
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
