Table 5 AIC, Fuse and Wire sizes
Voltage
class
Applicable
motor [kW]
Inverter model
UL
output current
(A) *2, *3
AIC (A)
(Interrupting
capacity)
Fuse class and
current
(A)
Wire sizes of
power circuit
0.4 VFAS1-2004PL 2.5 (EH=) AIC 5000A CC 7Amax. AWG 14
0.75 VFAS1-2007PL 4.8 (EH=) AIC 5000A J 15Amax. AWG 14
1.5 VFAS1-2015PL 7.8 (EH=) AIC 5000A J 25Amax. AWG 14
2.2 VFAS1-2022PL 11.0 (EH=) AIC 5000A J 25A max. AWG 12
3.7/4.0 VFAS1-2037PL 17.5 (EH=) AIC 5000A J 45Amax. AWG 10
5.5 VFAS1-2055PL 25.3 (EH=) AIC 5000A J 60Amax. AWG 8
7.5 VFAS1-2075PL 32.2 (EH=) AIC 5000A J 70Amax. AWG 8
11 VFAS1-2110PM 48.3 (EH=) AIC 5000A J 90Amax. AWG 4
15 VFAS1-2150PM 62.1 (EH=) AIC 5000A J 110Amax. AWG 4
18.5 VFAS1-2185PM 74.8 (EH=.) AIC 5000A J 125Amax. AWG 3
22 VFAS1-2220PM 88 (EH=.) AIC 5000A J 150Amax. AWG 2
30 VFAS1-2300PM 114 (EH=.) AIC 5000A J 200Amax. AWG 2/0
37 VFAS1-2370PM 143 (EH=.) AIC 5000A J 225Amax. AWG 3/0
45 VFAS1-2450PM 169 (EH=.) AIC 10000A J 300Amax. AWG 4/0
55 VFAS1-2550P 221 (EH=.) AIC 10000A J 350Amax. 2 × AWG 3/0
200V
class
75 VFAS1-2750P 285 (EH=.) AIC 10000A J 450Amax. 2 × AWG 4/0
0.75 VFAS1-4007PL 2.1 (EH=) AIC 5000A CC 6Amax. AWG 14
1.5 VFAS1-4015PL 3.4 (EH=) AIC 5000A CC 12Amax. AWG 14
2.2 VFAS1-4022PL 4.8 (EH=) AIC 5000A J 15Amax. AWG 14
3.7/4.0 VFAS1-4037PL 7.6 (EH=) AIC 5000A J 25Amax. AWG 12
5.5 VFAS1-4055PL 11.0 (EH=) AIC 5000A J 40Amax. AWG 10
7.5 VFAS1-4075PL 14. 0 (EH=) AIC 5000A J 40Amax. AWG 10
11 VFAS1-4110PL 21.0 (EH=) AIC 5000A J 60Amax. AWG 8
15 VFAS1-4150PL 27.0 (EH=) AIC 5000A J 70Amax. AWG 6
18.5 VFAS1-4185PL 34.0 (EH=) AIC 5000A J 70Amax. AWG 6
22 VFAS1-4220PL 40.0 (EH=) AIC 5000A J 80Amax. AWG 6
30 VFAS1-4300PL 52.0 (EH=) AIC 5000A J 90Amax. AWG 4
37 VFAS1-4370PL 65.0 (EH=.) AIC 5000A J 110Amax. AWG 3
45 VFAS1-4450PL 77.0 (EH=.) AIC 10000A J 150Amax. AWG 1
55 VFAS1-4550PL 96.0 (EH=.) AIC 10000A J 175Amax. AWG 1/0
75 VFAS1-4750PL 124.0 (EH=.) AIC 10000A J 225Amax. AWG 3/0
90 VFAS1-4900PC 179.0 (EH=.) AIC 10000A J 300Amax.
AWG 1/0 × 2
250 MCM × 2 *1
110 VFAS1-4110KPC 215.0 (EH=.) AIC 10000A J 350Amax.
AWG 3/0 × 2
250 MCM × 2 *1
132 VFAS1-4132KPC 259.0 (EH=.) AIC 10000A J 350Amax.
AWG 4/0 × 2
250 MCM × 2 *1
160 VFAS1-4160KPC 314.0 (EH=.) AIC 18000A J 400A max.
300 MCM × 2
350 MCM × 2 *1
200 VFAS1-4200KPC 387.0 (EH=.) AIC 18000A J 500Amax.
AWG 4/0 × 3
350 MCM × 3 *1
220 VFAS1-4220KPC 427.0 (EH=.) AIC 18000A J 500Amax.
250 MCM × 3
350 MCM × 3 *1
280 VFAS1-4280KPC 550.0 (EH=.) AIC 18000A J 700Amax.
350 MCM × 3
350 MCM × 3 *1
355 VFAS1-4355KPC 671.0 (EH=.)
400 VFAS1-4400KPC 759.0 (EH=.)
400V
class
500 VFAS1-4500KPC 941.0 (EH=.)
*1: This part shows the wiring size with using the Lug terminal.
The Lug terminals are an option.
*2: UL output current is different from unit rating output current.
*3: UL output current when the PWM carrier frequency(parameter CF) is 4 or 2.5.
9.2.4 Caution as to the protection of motors from overload
When using the inverter’s thermal protection function to protect the motor from overload, read the instruction manual
included with the inverter carefully and set parameters according to the specifications of the motor used.
When using the inverter to control the operation of multiple motors, install an overload relay for each individual motor.
n overload relay for each individual motor.
