Trinix NXT — Installation and Service Manual
401
Matrix board - DM-33100
Part side
Ref
Display
Meaning
PALARM DS952 Red
Primary alarm for this board. A DC supply has failed on the board or
the microcontroller
Off
Board OK
3V3
DS951
Green
3V3 is OK
Off
Check 3V3
INUSE
DS901
Yellow
1 or more CrossPoints now in use on this board
Off
No CrossPoints in use on this board
-3V3
DS31
Green
-3V3 is OK
Off
Check -3V3
DONE
DS950
Green
The Xilinx FPGAs are properly configured
Off
FPGAs failed to configure
