Trinix NXT — Installation and Service Manual 121
Configuration
Configuration
Quick Look
Building Block Size: 32 Inputs or 32 Outputs
Options: 3G, HD, or SD rate I/O modules
Dual outputs (3G, HD, and SD), quad outputs (HD and SD
only)
Additional monitor outputs (2)
Redundant sync inputs (2)
Redundant monitor/status/control
Redundant power supplies
Standards Supported: SMPTE 259M-1997, SMPTE 292M-1998, SMPTE 424M
Standard Connectors: 75-Ohm BNC
Output Monitor: Yes, 2 standard
Sync Reference Input: Yes, 2. Granularity: per 32 outputs
Control Options: Jupiter, SMS 7000, Encore
Frame, Board, Weight, and Power Summary for Select Matrix Sizes
The following tables provide a summary of the information for all of the
Trinix frames. All weights are approximations.
Table 17. 128x128 Matrix Specifications
* Approximate
Matrix Size
32
x
32
64
x
64
96
x
96
128
x
128
# of Frame 1 1 1 1
# Input Boards 1 2 3 4
# Output Boards 1 2 3 4
# of Matrix Boards 1 1 1 1
Weight in pounds
(kilograms) 75
(34)
81
(37)
88
(40)
94
(43)
Power Consumption* (W) ~350 ~400 ~440 ~480
