Trinix NXT — Installation and Service Manual
Section 3 — Hardware Installation
Figure 74. TRX-NXT-512x1024 Asymmetric Frame, Front and Back
Fan modules
DC Power inputs
Matrix and Sec-
ondary Broadlinx
boards
Fan modules
Output Boards
Input Boards
Output Boards
DC Power inputs
Matrix and Primary
Broadlinx boards
