Trinix NXT — Installation and Service Manual 213
Frame Number Settings
Table 48. Frame Numbering (cont.)
The 256X512 router is a subset of the 512X512router and it operates as a par-
tially stuffed 512X512 system.
Table 49. Frame Numbering (cont.)
TRX-NXT-512x512 and 256x512*
FRAME NUMBER
INPUTS
1537-2048* 5 7 13 15
1025-1536* 4 6 12 14
513-1024* 1 3 9 11
1-512* 0 2 8 10
OUTPUTS 1-512* 513-1024* 1025-1536* 1537-2048*
TRX-NXT-512x1024
FRAME NUMBER
INPUTS
1537-2048* 5 13
1025-1536* 4 12
513-1024* 1 9
1-512* 0 8
OUTPUTS 1-1024 1025--2048
*For Jupiter-controlled (0-based) systems, subtract one (1) from these input/output numbers.
