114 Trinix NXT — Installation and Service Manual
Section 2 — Planning Guide
256X512 Asymmetric Sync Inputs
Level: Nominal 1 Vp-p (+/-6 dB) video or black burst
Tri-level sync also accepted
Video Standard: NTSC/PAL/HDTV, auto-detected
Return Loss: >/= 36dB from 100 KHz to 5 MHz
>/= 30dB from 5 MHz to 10 MHz
>/= 20dB from 10 MHz to 30 MHz
128x256 Asymmetric Sync Inputs
Level: Nominal 1 Vp-p (+/-6 dB) video or black burstTri-level sync
also accepted
Video Standard: NTSC/PAL/HDTV, auto-detected
Return Loss: >/= 40dB from 100 KHz to 20 MHz
>/= 30dB from 20 MHz to 30 MHz
Serial Digital Outputs
Level: 800 mV p-p +/-10% 75-ohm
Return Loss: 3G: >/= 15 dB from 5 MHz to 3 GHz (Typical).
HD: >/=15 dB from 5 MHz to 1.5 GHz
Performance Characteristics
Maximum data rate: 3.0 Gb/s for 3G, 1.5 Gb/s for HD, and 540 Mbps for SD
Minimum Data Rate : 270Mbps for 3G/s circuit boards and 3.072 Mbps for HD and
SD circuit boards.
Signal Standards: SMPTE 292M-1998,
1
SMPTE 259M-1997
1
(Output rise and fall
times correspond to SMPTE 292M).
The HO-3G conforms to SMPTE 259M (270 Mb/S), 292M
(1.5Gb/S) and 424M (3Gb/S). The output rise and fall times
adjust according to the detected data-rate.
Equalization: HI-3G Input board: For SD operation, equalization is automatic
up to 380 meters using Belden 8281 (or an equivalent coax
cable) and 500 meters using Belden 1694A. For HD operation,
equalization is automatic up to 160 meters of Belden 1694A or
an equivalent coax cable. For 3Gp/s operation, equalization is
automatic up to 140 meters of Belden 1694A, when installed in
a Trinix
NXT
frames.
1. See Glossary
