Trinix NXT — Installation and Service Manual

399

Matrix board - DM-256R-3G and DM-256-3G

Part side

Matrix board - DM-256R-3G and DM-256-3G (Mezzine)

Part side

Ref

Display

Meaning

ALARM DS3

Red

Primary alarm for this board. A DC supply has failed on the board or
the microcontroller

Off

Board OK

XC DONE

DS4

Green

The FPGA is properly configured

Off

FPGA failed to configure

IN USE A

DS5

Yellow

CrossPoint is being used (Both CrossPoints can be “in Use” at the
same time)

Off

XPT A is not being used

PS1 FAIL

DS1

Red

XPT ’s power has failed

Off

XPT’s power is OK

IN USE B

DS7

Yellow

CrossPoint is being used (Both CrossPoints can be “in Use” at the
same time)

Off

XPT B is not being used

PS FAIL

DS2

Red
