282 Trinix NXT — Installation and Service Manual
Section 5 — Broadlinx Installation
Updating Broadlinx Using NetConfig
Pre-Installation Steps
Note Please read the Requirements on page 281 before proceeding.
Before Starting the update using NetConfig:
• Place the latest broadlinx.tar file in the Trinix directory of the Matrices
folder (….\Encore\Matrices\Trinix).
• Place the trinix.xml file in the Netconfig directory.
Note If Encore was installed in directories other than the default, you will need to
edit the element in the trinix.xml file to match the location of
broadlinx.tar.
Installation Steps
Follow these steps to update Broadlinx using NetConfig:
1. Start NetConfig and Verify that you are using the 2.0.13 version.
a. Click the About button on the NetConfig tool bar. The About
Network Configuration Tool dialog box will then appear.
b. The version is displayed above the copyright notice. If the installed
version is older than 2.0.13, you will not be able to perform this
update.
c. Click the OK button to close the dialog box.
2. Click the Load Software button on the NetConfig tool bar, or select
Configure > Load Software. A window showing a hierarchy of the
software available will then appear.
3. Click Routers > Encore> Matrices> Trinix (Broadlinx version #) in the
left side window, then select Broadlinx. This will display the software
versions available for loading in the right panel (
Figure 194 ).
Figure 194. NetConfig’s Load Software Window
The destina-
tions for the
software
The available
versions of
software
