164 Trinix NXT — Installation and Service Manual
Section 3 — Hardware Installation
TRX-NXT-512x512 with Multi Sync References
Figure 83.
In TRX-NXT-512x512 routing switchers, which are normally supplied with
an SR-33500 Sync/OPM board, up to four independent sync sources can be
connected and any of the four can be selected for each output board.
For a discussion concerning which of the four sync references should be
connected to the control system, see
Sync Connection to Control System .
The “C” switch mentioned here and on the following drawings in on the
Trinix rear panel.
Jupiter
Sync 1
1
2
3
4
SR-33500
Output
board(s)
on SL1
Output
board(s)
on SL2
Output
board(s)
on SL3
Output
board(s)
on SL4
Sync Lines
Sync 2
Sync 3
Sync 4
SMS MCPU
Sync 1
or
Encore SCB
OR
Sync Redundant switch = Off
“C” switch = Off
Sync
1
