Trinix NXT — Installation and Service Manual 385
TRX-VI-33100 Module
Table 117. Video Processing Selections
Figure 269. Video processing menu for NTSC, showing setup for all 16 inputs. PAL display is
similar. (Only Input 0 is connected in this example.)
Video Processor -
--------------------------------------------------------------------------------
Reference - Input 0: Line Rate: 525 Line Type: NTSC (M, J)
================================================================================
Disable (Off) 0
Enable (On) 1
Contrast/Y Gain: Brightness/Y Offset:
50.0% to 200.0% (0.5% steps) -100.1 to +100.1Deg (0.7mV steps)
Saturation/Chroma Gain: Hue/Chroma Phase:
50.0% to 200.0% (0.5% steps) -180.0 to +180.0Deg (1.0Deg steps)
--------------------------------------------------------------------------------
+------------------------------------------- Channel Line Rate --------+
| |
| +----------------------------------- Insert EDH (On/Off) |
| | +------------------------------- Contrast / Y Gain (%) |
| | | +---------------------- Saturation / Chroma Gain (%) |
| | | | +-------------- Brightness / Y Offset (mV) |
| | | | | +------ Hue / Chroma Phase (Deg) |
+---+---+--------+-------+-------+-------------------------------------------+--
0, 0, 100.0, 100.0, +000.0, +000.0 525
1, 0, 100.0, 100.0, +000.0, +000.0 N/A
2, 0, 100.0, 100.0, +000.0, +000.0 N/A
3, 0, 100.0, 100.0, +000.0, +000.0 N/A
4, 0, 100.0, 100.0, +000.0, +000.0 N/A
5, 0, 100.0, 100.0, +000.0, +000.0 N/A
6, 0, 100.0, 100.0, +000.0, +000.0 N/A
7, 0, 100.0, 100.0, +000.0, +000.0 N/A
8, 0, 100.0, 100.0, +000.0, +000.0 N/A
9, 0, 100.0, 100.0, +000.0, +000.0 N/A
a, 0, 100.0, 100.0, +000.0, +000.0 N/A
b, 0, 100.0, 100.0, +000.0, +000.0 N/A
c, 0, 100.0, 100.0, +000.0, +000.0 N/A
d, 0, 100.0, 100.0, +000.0, +000.0 N/A
e, 0, 100.0, 100.0, +000.0, +000.0 N/A
f, 0, 100.0, 100.0, +000.0, +000.0 N/A
Press: '0 ~ 9' or 'A ~ F' to select channel to edit.
Press: 'M' to move/copy channel configuration.
Press: 'Z' to set ALL channels to factory defaults.
Press 'ESC' to return to Main Menu.
When an input (channel) is selected, the display will show the values for
that particular channel:
Figure 270. Video processing setup menu for one channel (NTSC shown).
Video Processor -
--------------------------------------------------------------------------------
Reference - Input 0: Line Rate: 525 Line Type: NTSC (M, J)
================================================================================
Selected - Input 0: Line Rate: 525 Line Type: NTSC (M, J)
--------------------------------------------------------------------------------
Disable (Off) 0
Enable (On) 1
Contrast/Y Gain: Brightness/Y Offset:
50.0% to 200.0% (0.5% steps) -100.1 to +100.1Deg (0.7mV steps)
Saturation/Chroma Gain: Hue/Chroma Phase:
Processing
Function
Type
Default
Range/Choices
Resolution
Insert EDH 0 1 = Allows EDH to be inserted
Contrast / Y Gain 100%
50–200%
(0.5% steps)
Saturation / Chroma Gain 100%
50–200%
(0.5% steps)
Brightness / Y Offset 0 Mv
±400 mV
(3 mV steps)
Hue / Chroma Phase 0 degrees
±180 degrees
(1.4 degree steps)
