Trinix NXT — Installation and Service Manual 103
Protected Paths
The maximum number of Protected paths for a TRX-NXT-128x128 router is
64.
A more detailed example is shown in Table 11 . This table shows a sequen-
tial wiring scheme for a system yet to be installed or a system where cables
will be re-arranged in a symmetrical pattern in order to simplify Protected
path operation.
The numbers shown here correspond to the connector numbers used
during router configuration (but not, in most cases, to the actual silk screen
number on the rear panel itself since the silk screen numbers only run from
1” to 32.”)
In Jupiter-controlled systems, the Name column in these tables corre-
sponds to the logical input/output name”; the entries in the number
column will correspond to the physical” input/output number.
The next example applies to existing systems where re-arrangement of
cables in a sequential pattern is not practical or desirable:
Notice that I/O numbers conform to the ranges that are shown in Table 10
Recommended Protected Path Ranges on page 102.
Table 11. TRX-NXT-128x128 Protected Paths (Example Of Sequential Numbering)
Primary Path Secondary Path
Out In Out In
Name No. Name No. Name No. Name No.
AirPP 1 MCPP 1 AirSP 33 MCSP 33
Sat1PP 2 StuAPP 2 Sat1SP 34 StuASP 34
Sat2PP 3 StuBPP 3 Sat2SP 35 StuBSP 35
. . . .
. . . .
. . . .
NetPP 64 MainPP 64 NetSP 128 MainSP 128
Table 12. TRX-NXT-128x128 Protected Paths (Example Of Non-sequential Numbering)
Primary Path Secondary Path
Out In Out In
Name No. Name No. Name No. Name No.
AirPP 21 MCPP 12 AirSP 33 MCSP 33
Sat1PP 53 StuAPP 54 Sat1SP 1 StuASP 1
Sat2PP 109 StuBPP 95 Sat2SP 96 StuBSP 64
