172 Trinix NXT — Installation and Service Manual
Section 3 — Hardware Installation
TRX-SR V Phase and Source Information
Table 30 shows the switches providing adjustment for TRX-SR, S2.
Table 30. Switch Point Shift for TRX-SR, S2
Table 31 shows the switches providing adjustment for TRX-SR, S3.
Table 31. Switch Point Shift for TRX-SR, S3
Table 32 shows the switches providing Status for the Source Select DIP
Switch S1.
TRX-SR, S2:1-3
Reference 1
TRX-SR, S2:4-6
Reference 2
-1.0 line On, On, On, On, On, On,
-0.5 line Off, On, On Off, On, On
Coincident (default) On, Off, On On, Off, On
+0.5 line Off, Off, On Off, Off, On
+1.0 line On, On, Off On, On, Off
+1.5 line Off, On, Off Off, On, Off
+2.0 line On, Off, Off On, Off, Off
+2.5 line Off, Off, Off Off, Off, Off
Out Monitor Boost En S2:8 On = En S2:8 Off = Dis
TRX-SR, S3:1-3
Reference 1
TRX-SR, S3:4-6
Reference 2
-1.0 line On, On, On, On, On, On,
-0.5 line Off, On, On Off, On, On
Coincident (default) On, Off, On On, Off, On
+0.5 line Off, Off, On Off, Off, On
+1.0 line On, On, Off On, On, Off
+1.5 line Off, On, Off Off, On, Off
+2.0 line On, Off, Off On, Off, Off
+2.5 line Off, Off, Off Off, Off, Off
