General notes about the setup application editor
Here are a few conventions about the setup application editor
that may be helpful to know:
•
Tables are edited using keyboard shortcut keys (not the
mouse or cursor keys). The applicable shortcuts are listed
on the bottom of the display.
•
The first step is usually selection of one of the 16 inputs
(channels).
•
Channel numbers are hex-based. E.g., channel “a” on this
table is as input “11” on the rear panel of the router. A table
of equivalent channel numbers is shown below in
.)
•
For entries where ON or OFF is selected, 0 = OFF and 1 =
ON.
382
Trinix NXT — Installation and Service Manual
Section 11 — Analog Input Processing
Table 115. Channel Number Equivalents.
Input number
as on router
rear panel
Correspondin
g input
number as
shown on
table
1
0
2
1
3
2
4
3
5
4
6
5
7
6
8
7
9
8
10
9
11
a
12
b
13
c
14
d
15
e
16
f
