Trinix NXT — Installation and Service Manual
137
Summary of Installation Procedure
Figure 64. TRX-NXT-256 X 256 Front View (door removed).
OK
DC
VADJOK
AC
DC
OK
AC
OK
VADJ
F
AN ALARM
F
AN ALARM
F
AN ALARM
SR-33000 Sync Reference /
NR-33000 Broadlinx Board
slots
Fan modules
Power supplies
Matrix boards
Input/output
boards
(configuration
varies)
