Audio Configuration Monitor Channels Tab
Profile Family 99
To change the input clocking:
1. Choose Option | Audio Configuration Board 1 or 2 or click an ASPB
Configuration button . The Audio Configuration dialog box appears. Click
the Input Clocking tab, if it isn’t already displayed.
2. Click the button in the Audio Clock Reference Source column for the desired
channels and select one of up to five choices: System (default) or Video
Input. (The number of video inputs depends on the number of available video
channels.) Selecting one of the video inputs sets the group of four channels
to use the selected input as their audio clocking source.
3. Click OK to accept your changes or click another tab.
Audio Configuration Monitor Channels Tab
Under the Monitor Channels tab, you can select recording and playback quality
and adjust monitor channels.
1. Choose Option | Audio Configuration Board 1 or 2 or click an ASPB
Configuration button. The Audio Configuration dialog box appears (Figure
43).
Figure 43. Audio Configuration dialog box, Monitor Channels tab
