Configuring Audio Resources
Profile Family 327
Configuring Audio Resources
Configuring audio resources for a channel involves adding one or more audio
tracks to the channel, and selecting an audio input for each track. When you
select the audio input for the track, the corresponding output is automatically
selected. For instance, if you select AES/EBU-In1-J5 for your input,
AES/EBU-Out1-J5 is automatically selected as the output. Likewise, if you
select an output, the corresponding input is automatically selected.
To configure audio resources:
1. Select the audio Track icon in the configuration tree. With the Crosspoints
button selected, the Audio Input and Output check boxes appear at the
bottom of the Resource Manager dialog box (see Figure 158).
Figure 158. Audio inputs and outputs
