Chapter 8
Using the Tool Box Editor
260
Profile Family
Figure 120. Current bin display
Below the current bin display is a set of buttons (from left to right):
• Load Media: Loads a selected master onto the edit timeline or a selected clip
onto the capture timeline.
• Insert Media: Inserts a selected clip into the currently loaded master on the
edit timeline near the location of the current timeline cursor.
• Timeline Eject: Ejects media from the active timeline.
• New Master: Creates a new, empty master, ready to receive clips.
• New Bin: Creates a new bin within a volume and displays it in the current
bin display.
• Open Bin: Opens an existing bin and displays it on the current bin display.
• Delete Media: Deletes selected media.
Load Media
Timeline Eject
New Master
Open Bin
New Bin
Delete Media
Bin Toolbar
Insert Media
Undo Redo
