Chapter 2 Using the Profile Configuration Manager
100 Profile Family
2. Click the Monitor Channels tab.
3. Under Monitor Channels, the Channel Selection box allows you to select
which channels you want to monitor. Click next to a channel pair to select
them. You can now adjust line levels for the pair.
4. The line level range is –12 to +0 dB. If you trim the line level for an
individual channel with the slider handle, the line level is incremented by 1
dB; clicking on either side of the slider handle increments the line level by
0.5 dB. The
Level boxes show the current line level. If you enter a number
directly into a Level box, the line level number is rounded to the nearest
±
0.5
dB.
5. To adjust the trim for all channels at once, use the Group Fader slider. While
the Group Fader moves all channels at once, it maintains the individual
channel differences.
NOTE: If the audio interface box is not present, the Monitor group
will not appear. If your system is configured with an XLR 216 digital-
only chassis, channel selection is the only option available in the
Monitor Channels group.
6. Click OK to accept your changes or click another tab.
