Chapter 3 Using Media Manager
154 Profile Family
The labels in the dialog box are explained here:
To add a transport to the list of active transports:
1. In the tree pane, select the appropriate library icon.
2. Choose Tape Transport Status from the File menu, or from the shortcut
menu with a right-click. The Tape Transport Status dialog box appears.
3. Click the Add button. The Add Tape Transport dialog box appears, as shown
in Figure 74.
Transport Icon A transport icon is shown for each active transport
in the library. The order of transports in this dialog
does not necessarily reflect the order they appear in
the library system.
Transport Number This is the logical identifier for the transport. It is a
number from 0–255.
Robot Position This is the physical transport identifier. It is a num-
ber from 0–3.
Cartridge Name A cartridge name is shown if one is currently loaded
into the transport.
Disable Removes a transport from service. Click Add to re-
enable the transport.
Clean Loads a cleaning cartridge and cleans the transport
Cleaning Message The message Needs Cleaning appears when the
transport is due for cleaning.
Add Adds a transport to the list of available transports.
Close Close the Tape Transport Status dialog.
Help Opens the help topic on the Tape Transport Status
dialog.
