Chapter 2 Using the Profile Configuration Manager
84 Profile Family
Analog Audio Input
In analog audio input, you can change audio channel names, check the channel
overload status, or adjust line levels in decibels. Click
Undo to cancel changes,
or click Help for context-sensitive Help. To configure analog audio input:
1. Expand Audio Input , and then click one of the Analog Channels. The
Analog Audio Input dialog box appears (Figure 31). The channel numbers
on the left refer to the physical input connectors on the audio input box. Ch.
01 refers to the first connector, and Ch. 02 refers to the second connector,
and so forth.
Figure 31. Analog Audio Input dialog box, Main tab
2. Click the Main tab, if it is not already visible.
3. Click in the box of the input channel whose name you want to change. A
channel name can have up to 30 characters.
4. After you have changed the channel names, click Close or another tab.
