Using the Profile Protocol Resources Utility
Profile Family 219
The Add Video , Add Audio , and Add Timecode buttons add the resources you
select to the configuration file under construction. Each time you click the “Add”
button for a set of resources, the resources are tagged as “Used” except for shared
resources, such as a Video Input, which you can use several times.
The Clear button removes the “Used” tags from resources that have been added
but not yet saved; the Clear All button clears all “Used” tags in the dialog box,
including those for resources that have been saved. The Create File button allows
you to save the temporarily stored information in the permanent configuration file.
Resources being used by other applications (such as VdrPanel) are tagged as “In
Use.” If you wish to add “In Use” resources to the configuration file, exit Profile
Protocol Resources, free the resources in the other Profile applications, then restart
Profile Protocol Resources.
To create a configuration file:
1. Select the video input, codec or encoder, and video output you wish to add
to the configuration file and click the Add Video button. If you wish to
assign more than one video codec or encoder to a channel, repeat the process.
If you select a JPEG codec, a dialog box appears similar to the one shown in
Figure 111; if you select an MPEG encoder, a dialog box appears similar to
the one shown in Figure 112. Make appropriate compression settings for
your recordings and click
OK .
Refer to “Using VdrPanel” on page 159 for an explanation of these settings.
Figure 111. Setting JPEG compression
