Grass Valley PROFILE FAMILY v.2.5 - Manual (Page 50)

Chapter 2 Using the Profile Configuration Manager
50 Profile Family
Changing LTC Input and Output Names
The LTC (longitudinal timecode) inputs and outputs dialog box allows you to
rename the LTC inputs and outputs.
To change an LTC name:
1. Click or double click LTC Input & Output in the configuration tree and LTC
Input & Output dialog box appears.
Figure 10. LTC Inputs & Outputs dialog box
1. Select an LTC input or output name.
2. Position the edit cursor within the appropriate edit box.
3. Enter the new name or portion of a name.
4. The new name appears in the name list.
5. Click Undo to return the name or names as they were at the time the dialog
box appeared.
6. Click Close to accept the new LTC name or names.
