Chapter 3 Using Media Manager
142 Profile Family
- To import a new cleaning cartridge, click Import new cleaning
cartridge . The library system cannot differentiate between a cleaning
cartridge and an ordinary cartridge. It must be told when a cleaning
cartridge is imported. If you provide a unique tape label, the cleaning
cartridge is stored in a cleaning cartridge bin.
5. Click Import .
6. A prompt appears requesting that you physically insert the cartridge into the
library. Once the robot is in position and you insert the cartridge, press any
button on the library’s control panel.
7. The Importing Cartridge dialog box remains on the screen until the robot
puts the cartridge in the available slot. Since this is done in the background,
click
OK at any time.
When the robot retracts with the imported cartridge, it scans the cartridges’s
barcode. If the barcode does not match the name that was entered for the import,
it is rejected.
Exporting a Cartridge
To export a cartridge is to eject or remove it from the library system:
1. In the tree pane, select the icon for the cartridge you want to export.
2. Choose Export Cartridge from the File menu, or from the shortcut menu
with a right-click, and the Export Cartridge dialog box appears. By default,
the cartridge location is Out of library.
Figure 64. Export Cartridge dialog box
