Grass Valley PROFILE FAMILY v.2.5 - Manual (Page 267)

Capturing a New Clip
Profile Family 267
2. All acquired audio channels may be used when recording new clips.
However, you need to select a set of audio channels. To select a set of audio
channels for recording:
• Click the Audio Enable button.
• Enable audio channels by clicking on the channel selection button above the
appropriate audio meter. (See Figure 132)
3. Enter the new clip name in the Clip Name text box, or simply accept the
default. The default name automatically increments to a unique name. With
a right-click in the text box, you can choose from several editing commands.
Figure 126. Clip Name text box
4. Click on the Record button. You can also choose Record from the Media
menu or from the shortcut menu with a right-click.
5. When you are done recording, click on the Stop button. (See Figure 127)
Figure 127. Transport controls
Clip Name
Text Box
Play Stop Fast Forward Rewind Reverse Loop
Play
