Chapter 6 Using Profile Utilities
222
Resource Lines
Resource lines allocate a resource for use by a port. The following is the
column-by-column layout of resource lines:
• Column 1-2: resource type.
Must be one of the following:
• Column 3: separator (-).
• Column 4-5: resource number.
This specifies which resource of the specified type is desired. Resources of
a given type are numbered starting at 0. To select the third timecode recorder,
specify “02” in columns 4-5.
For inputs and outputs spread across multiple cards, devices are scanned
along the Profile EISA bus starting at slot 0. Viewed from the back of the
Profile system, numbers increment from right to left. In a Profile system with
two Serial Digital I/O cards, video input 00 represents the upper BNC
connector on the rightmost Serial Digital card, while video input 03
represents the second BNC connector on the leftmost Serial Digital card.
00 audio codec
01 JPEG codec
02 video input
03 video output
04 LTC input
05 VITC input
06 timecode generator
07 LTC output
08 VITC output
09 timecode recorder
10 audio output
11 video combiner (mix effect)
12 MPEG decoder
13 MPEG encoder
