Digital Audio Input
Profile Family 87
To check the status of digital input channels:
1. In the Digital Audio Input dialog box, click the Status tab. Under Status
Indicators, you see the error status of each channel. If a channel has an error,
the indicator is on. See Table 2 for a description of each error indicator.
Figure 34. Digital Audio Input dialog box, Status tab
2. When you are done checking for errors, click Close or another tab.
Table 2. Digital audio input channel indicators
Indicator Description
Unlocked Error Receiver unlocked
Validity Error AES receiver validity
Parity Error Parity error
CRC Error CRC subframe errors
Emphasis Detected emphasis
