Chapter 11 Using TimeDelay
346 Profile Family
Configuring Channels with Resource Manager
The Resource Manager is used for creating and configuring all TimeDelay
channels. In TimeDelay, the first channel (labeled “Recorder” in Figure 172) is
always the record channel, and all other channels are playback channels. You
cannot remove the first two channels because TimeDelay always requires a
record channel and at least one playback channel. You can have as many as 6
playback channels.
For more detailed information about using Resource Manager, refer to “Using
the Resource Manager” on page 313.
Adding a Playback Channel
To add a playback channel:
1. Choose Config | Resource Manager… to open Resource Manager.
2. Click the Add Channel button. This creates a new channel tab in the
Resource Manager dialog box.
3. Configure the new channel as necessary. Instructions for using Resource
Manager are in “Using the Resource Manager” on page 313.
4. Click the OK button.
When you close the Resource Manager dialog box, a new playback panel is
displayed in the TimeDelay window.
Deleting a Playback Channel
To remove a playback channel:
1. Choose Config | Resource Manager… to open Resource Manager.
2. Click on the channel tab that you want to remove.
3. Click the Remove Channel button to delete the selected channel tab.
4. Click the OK button.
When you close the Resource Manager dialog box, the panel that corresponded
to the removed channel is no longer displayed in the TimeDelay window.
