Chapter 2 Using the Profile Configuration Manager
38 Profile Family
To select an item from the configuration tree:
• ²The configuration tree appears on the left side of the window. Clicking on
an entry, such as Video Input , expands the list of choices. Clicking on an
expanded list of choices, such as if you click on Video Input a second time,
collapses the list of choices.
• ²A single click opens the specific dialog box, closing a previously opened
box, if necessary. A double-click opens the specific dialog box but does not
close any other open dialog boxes. To close all open dialog boxes at once,
choose
Window | Close All .
All changes in a dialog box take place immediately. The Undo button will undo
changes from the time a dialog box was opened in the current tab of the dialog
box. The
Undo button is dimmed if there is nothing to undo. The Help button
opens context-sensitive help related to the current dialog box.
By default, the toolbar and status bar are shown in the Configuration Manager
window. To hide the toolbar or status bar:
• Choose View | Toolbar or View | Status Bar .²
To view information about installed boards:
• Choose Help | Installed Boards Information .
