9469300990 Rev B 373
Fault
Code String Description
358 OPN LD CYLNDR B8 Open load in injector cable of cylinder B8.
359 OPN LD CYLNDR B9 Open load in injector cable of cylinder B9.
360 OPN LD CYLNDR B10 Open load in injector cable of cylinder B10.
361 AL POWER STAGE LOW Internal error of electronic.
362 AL POWER STAGE HIGH Internal error of electronic.
363 AL STOP POWER STAGE Internal error of electronic.
364 AL STOP POWER STAGE 2 Internal error of electronic.
365 AL MV WIRING GND Cable line error.
371 AL WIRING TO 1 Short circuit or open load on transistor output 1 (TO 1).
372 AL WIRING TO 2 Short circuit or open load on transistor output 2 (TO 2).
373 AL WIRING TO 3 Short circuit or open load on transistor output 3 (TO 3).
374 AL WIRING TO 4 Short circuit or open load on transistor output 4 (TO 4).
381 AL WIRING TOP 1 Short circuit or open load on transistor output plant 1 (TOP 1).
382 AL WIRING TOP 2 Short circuit or open load on transistor output plant 2 (TOP 2).
383 AL WIRING TOP 3 Short circuit or open load on transistor output plant 3 (TOP 3).
384 AL WIRING TOP 4 Short circuit or open load on transistor output plant 4 (TOP 4).
385 AL WIRING TOP 5 Short circuit or open load on transistor output plant 5 (TOP 5).
386 AL WIRING TOP 6 Short circuit or open load on transistor output plant 6 (TOP 6).
390 AL MCR EXCEEDED DBR/MCR Function: MCR (Maximum Continuous Rating) in
exceeded.
392 HI T COOLNT R Redundant coolant temperature too high (limit 1).
393 SS T COOLNT R Redundant coolant temperature too high (limit 2).
394 LO P LUBE OIL R Redundant pressure of lube oil too low (limit 1).
395 SS P LUBE OIL R Redundant pressure of lube oil too low (limit 2).
396 TD T COOLANT Maximum deviation of T-Coolant sensors.
397 TD P LUBE OIL Maximum deviation of P-Oil sensors.
399 AL INTERFACE ECU Interface ECU.
400 AL OPN LD DIGIN 1 Open load on digital input 1.
401 AL OPN LD DIGIN 2 Open load on digital input 2.
402 AL OPN LD DIGIN 3 Open load on digital input 3.
403 AL OPN LD DIGIN 4 Open load on digital input 4.
404 AL OPN LD DIGIN 5 Open load on digital input 5.
405 AL OPN LD DIGIN 6 Open load on digital input 6.
406 AL OPN LD DIGIN 7 Open load on digital input 7.
407 AL OPN LD DIGIN 8 Open load on digital input 8.
408 AL OPN LD E STOP Open load on input for emergency stop.
410 LO U PDU Power driver voltage (injectors) too low (limit 1).
411 LOLO U PDU Power driver voltage (injectors) too low (limit 2).
412 HI U PDU Power driver voltage (injectors) too high (limit 1).
413 HIHI U PDU Power driver voltage (injectors) too high (limit 2).
414 HI L WATER FUEL PREFILT Water level of fuel prefilter too high (limit 1).
415 LO P COOLANT INTRCOOLR Coolant pressure of intercooler too low (limit 1).
416 SS P COOLANT INTRCOOLR Coolant pressure of intercooler too low (limit 2).
DGC-2020HD MTU Fault Codes
