9469300990 Rev B 245
ECU Parameter
Metric
Units
English
Units Update Rate SPN
∗
Winding 1 Temperature °C °F 1 s 1124
Winding 2 Temperature °C °F 1 s 1125
Winding 3 Temperature °C °F 1 s 1126
∗ SPN: Suspect Parameter Number
Table 67. Engine Configuration Parameters Obtained from CAN Interface
ECU Parameter
Metric
Units
English
Units Update Rate SPN
∗
Engine Speed at High Idle Point 6 rpm rpm 5 s 532
Engine Speed at Idle Point 1 rpm rpm 5 s 188
Engine Speed at Point 2 rpm rpm 5 s 528
Engine Speed at Point 3 rpm rpm 5 s 529
Engine Speed at Point 4 rpm rpm 5 s 530
Engine Speed at Point 5 rpm rpm 5 s 531
Gain (Kp) of End Speed Governor %/rpm %/rpm 5 s 533
Maximum Momentary Engine Override Speed Point 7 rpm rpm 5 s 534
Maximum Momentary Engine Override Time Limit seconds seconds 5 s 539
Percent Torque at Idle Point 1 % % 5 s 540
Percent Torque at Point 2 % % 5 s 541
Percent Torque at Point 3 % % 5 s 542
Percent Torque at Point 4 % % 5 s 542
Percent Torque at Point 5 % % 5 s 543
Reference Engine Torque N•m ft-lb 5 s 544
Requested Speed Control Range Lower Limit rpm rpm 5 s 535
Requested Speed Control Range Upper Limit rpm rpm 5 s 536
Requested Torque Control Range Lower Limit % % 5 s 537
Requested Torque Control Range Upper Limit % % 5 s 538
∗ SPN: Suspect Parameter Number
Caution
When CAN is enabled, the DGC-2020HD ignores the following sender
inputs: oil pressure, coolant temperature, and magnetic pickup.
Under certain circumstances, the following strings may be displayed on the front panel and in the
Metering Explorer of BESTCOMSPlus:
•
NC (Not Connected) - String displayed for a J1939 parameter when the engine ECU is not connected
to the DGC-2020HD.
•
SF (Sender Fail) - String displayed for a J1939 parameter when the engine ECU sends a special
code indicating a measurement failure for the parameter. For example, if oil sender is determined to
be bad by the ECU, it sends a special code in place of the J1939 oil pressure data indicating a sender
fail condition.
DGC-2020HD Communication
