198 9469300990 Rev B
Menu Bars
The menu bars are located near the top of the BESTCOMSPlus window (see Figure 134). The upper
menu bar has five pull-down menus. With the upper menu bar, it is possible to manage settings files,
configure communication settings, upload and download settings/security files, and compare settings
files. The lower menu bar consists of clickable icons. These icons are used to change BESTCOMSPlus
views, save or load a BESTspace™ workspace, open a settings file, connect/disconnect, preview
metering printout, export metering, switch to live mode, and send settings after a change is made when
not in live mode.
Upper Menu Bar (BESTCOMSPlus ® Shell)
Upper menu bar functions are listed and described in Table 54.
Table 54. Upper Menu Bar (BESTCOMSPlus Shell)
Menu Item Description
File
New Create a new settings file
Open Open an existing settings file
Open File As Text Generic file viewer for
*.csv, *,txt, etc. files
Close Close settings file
Save Save settings file
Save As Save settings file with a different name
Export To File Save settings as a
*.csv file
Print Print, export, or send a settings file
Properties View properties of a settings file
History View history of a settings file
Recent Files Open a previously opened file
Exit Close BESTCOMSPlus program
Communication
New Connection Choose new device or DGC-2020HD
Close Connection Close communication between BESTCOMSPlus and DGC-
2020HD
Download Settings and Logic from
Device Download operational and logic settings from the device
Upload Settings and Logic to Device Upload operational and logic settings to the device
Upload Settings to Device Upload operational settings to the device
Upload Logic to Device Upload logic settings to the device
Download Security from Device Download security settings from the device
Upload Security to Device Upload security settings to the device
Configure Ethernet settings
Upload Device Files Upload firmware to the device
Tools
Select Language Select BESTCOMSPlus language
Activate Device Activate the DGC-2020HD plugin
Set File Password Password protect a settings file
Compare Settings Files Compare two settings files
Auto Export Metering Exports metering data on a user-defined interval
BESTCOMSPlus
® Software
DGC-2020HD
