Engine System Inputs
Stated accuracies are subject to the accuracy of the senders used. Values within these ranges are
deemed “good” and the DGC-2020HD will use them for the appropriate calculation and protection. Values
outside these ranges are deemed “failed” and the DGC-2020HD will begin timing towards a sender failure
condition.
Fuel Level Sensing
Resistance Range ............................ 0 to 250
Ω nominal
Terminals.......................................... 71 (FUEL +), 72 (FUEL –)
Coolant Temperature Sensing
Resistance Range ............................ 10 to 2,750
Ω nominal
Terminals.......................................... 77 (COOLANT +), 78 (COOLANT –)
Oil Pressure Sensing
Resistance Range ............................ 0 to 250
Ω nominal
Terminals.......................................... 74 (OIL +), 75 (OIL –)
Engine Speed Sensing
Magnetic Pickup
Voltage Range ................................. 3 to 35 V peak (6 to 70 V peak-peak)
Frequency Range ............................. 32 to 10,000 Hz
Terminals.......................................... 106 (MPU +), 107 (MPU –)
Generator Voltage
Range ............................................... 12 to 576 V rms
Terminals.......................................... 86 (A-phase)
88 (B-phase)
90 (C-phase)
91 (Neutral)
Output Contacts
PRE (Prestart), START, and RUN Relays
Rating ............................................... 30 Adc at 28 Vdc—General purpose, 3 A pilot duty
∗
Programmable Relays (12)
Rating ............................................... 2 Adc at 30 Vdc—General purpose, 1.2 A pilot duty
∗
∗The load must be in parallel with a diode rated at least 3 times the coil current and 3 times the coil
voltage.
DGC-2020HD Specifications
