MTU Fault Codes
A DGC-2020HD connected to a genset equipped with an MTU engine ECU tracks and displays the active
fault codes issued by the MTU engine ECU. Active MTU fault codes can be viewed through
BESTCOMSPlus
® by using the Metering Explorer to expand the MTU tree or through the front panel
display by navigating to Metering > Status > MTU Fault Codes.
Each fault code is displayed with a fault description and the fault number. If the DGC-2020HD does not
have descriptive information about a fault number that was received, the fault description will display
as “NO TEXT AVAILABLE”. Fault codes displayed by the DGC-2020HD are listed in Table 98.
Table 98. MTU Fault Codes
Fault
Code String Description
3 HI T FUEL Fuel temperature too high (limit 1).
4 SS T FUEL Fuel temperature too high (limit 2).
5 HI T CHRG AIR Charge air temperature too high (limit 1).
6 SS T CHRG AIR Air temperature too high (limit 2).
9 HI T INTERCOOLER Coolant temperature of intercooler too high (limit 1).
10 SS T INTERCOOLER Coolant temperature of intercooler too high (limit 2)
15 LO P LUBE OIL Pressure of lube oil too low (limit 1).
16 SS P LUBE OIL Pressure of lube oil too low (limit 2).
19 HI T EXHAUST A Exhaust gas temperature (A-side) too high (limit 1).
20 SS T EXHAUST A Exhaust gas temperature (A-side) too high (limit 2)
21 HIT T EXHAUST B Exhaust gas temperature (B-side) too high (limit 1).
22 SS T EXHAUST B Exhaust gas temperature (B-side) too high (limit 2).
23 LO COOLANT LEVEL Coolant level too low (limit 1).
24 SS COOLANT LEVEL Coolant level too low (limit 2).
25 HI P DIFF LUBE OIL Differential pressure of oil filter too high (limit 1).
26 SS P DIFF LUBE OIL Differential pressure of oil filter too high (limit 2).
27 HI LEVEL LEAKAGE FUEL Level of leakage fuel too high (limit 1).
29 HI ETC IDLE SPD TOO HI Idle speed of one of the switchable chargers too high.
30 SS ENGINE OVERSPEED Engine overspeed (limit 2).
31 HI ETC1 OVERSPEED Speed of basic charger too high (limit 1).
32 SS ETC1 OVERSPEED Speed of basic charger too high (limit 2).
33 L1 P FUELFLT DIF Differential pressure of fuel filter too high (limit 1).
36 HI ETC2 OVERSPEED Speed of 1 st switchable charger too high (limit 1).
37 SS ETC2 OVERSPEED Speed of 1 st switchable charger too high (limit 2).
38 AL ETC SPEED DEVIATION Speed deviation between basic turbocharger and one of the
switchable chargers.
39 AL ETC2 CUTIN FAIL Switching of charger ETC2 failed.
44 LO LEVEL INTRCLR Coolant level of intercooler too low (limit 1).
45 FAULT L2 LEVEL INTRCLR Coolant level of intercooler too low (limit 2).
51 HI T LUBE OIL Lube oil temperature too high (limit 1).
52 SS T LUBE OIL Lube oil temperature too high (limit 2).
57 LO P COOLANT Coolant pressure too low (limit 1).
58 SS P COOLANT Coolant pressure too low (limit 2).
