322 9469300990 Rev B
AEM-2020 DGC-2020HD
Figure 201. Settings Explorer, Programmable Outputs, Remote Analog Outputs, AEM 1 Output #1
Table 90. Settings for AEM x Output #y
Locator Setting Range Increment Unit
A Parameter Selection  n/a n/a
B Output Type Voltage or Current n/a n/a
C Out of Range Alarm Type
Status Only, Pre-
Alarm, or Alarm
n/a n/a
D Out of Range Activation Delay 0 to 300 1 seconds
E Param Min –999,999 to 999,999 0.1 n/a
F Param Max –999,999 to 999,999 0.1 n/a
G Min Output Current 4 to 20 0.1 milliamps
H Max Output Current 4 to 20 0.1 milliamps
I Min Output Voltage 0 to 10 0.1 volts
J Max Output Voltage 0 to 10 0.1 volts

See Parameter Selection, above.
Firmware Updates
Refer to the Device Information chapter for information on upgrading firmware in the AEM-2020.
Repair
Analog Expansion Modules are manufactured using state-of-the-art surface-mount technology. As such,
Basler Electric recommends that no repair procedures be attempted by anyone other than Basler Electric
personnel.
Before returning the AEM-2020 for repair, contact the Basler Electric Technical Services Department at
618-654-2341 for a return authorization number.
Maintenance
Preventive maintenance consists of periodically checking that the connections between the AEM-2020
and the system are clean and tight.
