264 9469300990 Rev B






=
Amps Primary CT
Amps Secondary CT
Amps Phase Rated Amps Phase Secondary Rated
Equation 7. Rated Secondary Phase Amps
Power Ratings
Rated Power Factor accepts a value from -1 to 1, in increments of 0.01.
Rated kW accepts a value from 0 to 1,000,000, in increments of 0.01.
Rated kVA is calculated using the following equation:
PF Rated
kW Rated
kVA Rated
=
Equation 8. Rated kVA
Rated kvar is calculated using the following equation:
2
PF Rated 1 kVA Rated kvar Rated
− =
Equation 9. Rated kvar
Sensing Configuration
Phase Rotation
Select either ABC (clockwise rotation) or ACB (counterclockwise rotation).
Voltage Sensing Connection Type
This setting provides selections for the voltage sensing connection type. Select Delta, Wye, Single-phase
A-B, Single-phase A-C, or Grounded Delta.
Current Sensing Connection Type
Selectable current sensing connections types are A, B, C, AB, BC, CA, or CT ABC.
Frequency
The frequency settings allow selection of the rated frequency of the generator and an alternate frequency.
Rated Frequency of the Unit
Rated frequency options are 50 and 60 Hz.
Alternate Frequency
This setting accepts values from 10 to 90, in increments of 0.01.
Battery Volts
Nominal voltage of the starter battery is used by the DGC-2020HD to detect and annunciate high, low, or
weak battery voltage. Battery Volts options are 12 V and 24 V.
Rated Engine RPM
This field accepts values from 1,400 to 2,000, in increments of 1.
Configuration DGC-2020HD
