9469300990 Rev B 155
Table 47. Settings for Configurable Protection
Locator Setting Range Increment Unit
A Label Text
Up to 16
alphanumeric
characters
n/a n/a
B Parameter Selection
∗
n/a n/a
C Arming Delay 0 to 300 1 seconds
D Hysteresis 0 to 100 0.1 %
E
Alternate Frequency Scale
Factor
0.001 to 100 0.001 n/a
F Voltage Low Line Scale Factor 0.001 to 3 0.001 n/a
G Current Low Line Scale Factor 0.001 to 3 0.001 n/a
H Mode
Disabled, Over, or
Under
n/a n/a
I Threshold –999,999 to 999,999 0.01 n/a
J Activation Delay 0 to 300 1 seconds
K Alarm Configuration
Status Only, Pre-
Alarm, or Alarm
n/a n/a
∗See Parameter Selection, above, for a complete listing of selectable parameters.
DGC-2020HD Configurable Protection
