4-2 Bulletin 283 Programmable Parameters
Parameter Group Listing The Bulletin 283 ArmorStart contains eight parameter groups. The
parameters shown in the DeviceLogix™, DeviceNet, Starter
Protection, User I/O, Misc. Parameter, ZIP Parameters, Soft Start
Display, and SoftStart Setup are discussed in this chapter.
Table 4.1 Parameter Group Listing
DeviceLogix DeviceNet Starter Protection User I/O Misc. ZIP Parameters Soft Start Display Soft Start Setup
1 Hdw Inputs 10 Autobaud Enable 22 Breaker Type 30 Off-to-On Delay 45 Keypad Mode 67 AutoRun Zip 101 Phase A Current 106 FLA Setting
2 Network Inputs 11 Consumed IO Assy 23 PrFltResetMode 31 On-to-Off Delay 46 Keypad Disable 68 Zone Produced EPR 102 Phase B Current 108 OL Reset Level
3 Network Outputs 12 Produced IO Assy 24 Pr Fault Enable 32 In Sink/Source 47 Set To Defaults 69 Zone Produced PIT 103 Phase C Current 109 Start Time
4 Trip Status 13 Prod Assy Word 0 25 Pr Fault Reset 33 OutA Pr FltState 56 Base Enclosure 70 Zone #1 MacId 104 Average Current 110 Start Mode
5 Starter Status 14 Prod Assy Word 1 26 StrtrDN FltState 34 OutA Pr FltValue 57 Base Option 71 Zone #2 MacId 105 % Therm Utilized 111 Current Limit
6 DNet Status 15 Prod Assy Word 2 27 StrtrDN FltValue 35 OutA DN FltState 58 Wiring Option 72 Zone #3 MacId 107 Overload Class 112 Initial Torque
7 Starter
Command
16 Prod Assy Word 3 28 StrtrDN IdlState 36 OutA DN FltValue 59 Starter Enclosure 73 Zone #4 MacId 113 Soft Stop Time
8 Network Override 17 Consumed IO Size 29 StrtrDN IdlValue 37 OutA DN IdlState 60 Starter Options 74 Zone #1 Health 114 Kick Start
9 Comm Override 18 Produced IO Size 61 Last Pr Fault 38 OutA DN IdlValue 75 Zone #2 Health
115 SCR Temp Rest
Mode
19 Starter COS Mask 62 Warning Status 39 OutB Pr FltState 76 Zone #3 Health 116 Phase Rotation
20 Net Out COS Mask 40 OutB Pr FltValue 77 Zone #4 Health
21 DNet Voltage 41 OutB DN FltState 78 Zone #1 Mask
42 OutB DN FltValue 79 Zone #2 Mask
43 OutB DN IdlState 80 Zone #3 Mask
44 OutB DN IdlValue 81 Zone #4 Mask
82 Zone #1 Offset
83 Zone #2 Offset
84 Zone #3 Offset
85 Zone #4 Offset
86 Zone #1 EPR
87 Zone #2 EPR
88 Zone #3 EPR
89 Zone #4 EPR
90 Zone #1 Control
91 Zone #2 Control
92 Zone #3 Control
93 Zone #4 Control
94 Zone #1 Key
95 Zone #2 Key
96 Zone #3 Key
97 Zone #4 Key
98 Device Value Key
99 Zone Ctrl Enable
