Renewal Parts
H-11
Bulletin 284, Continued
Table H.23
Bulletin 284 Control Module with Sensorless Vector
Performance, IP67/NEMA 4, Up to 480V
Table H.24
Bulletin 284 Control Module with Sensorless Vector
Performance, NEMA 4X, Up to 480V
Input Voltage
kW
Hp
Output
Current
24 V DC
Control Voltage
120 V AC
Control Voltage
240 V AC
Control Voltage
240V 50/60 Hz
3-Phase
0.4
0.5
2.3 A
284D-FHB2P3Z-N-R
284D-FHB2P3D-N-R
284D-FHB2P3B-N-R
0.7.5
1.0
4.5 A
284D-FHB4P5Z-N-R
284D-FHB4P5D-N-R
284D-FHB4P5B-N-R
1.5
2.0
7.6 A
284D-FHB7P6Z-N-R
284D-FHB7P6D-N-R
284D-FHB7P6B-N-R
480V 50/60 Hz
3-Phase
0.4
0.5
1.4 A
284D-FHD1P4Z-N-R
284D-FHD1P4D-N-R
284D-FHD1P4B-N-R
0.75
1.0
2.3 A
284D-FHD2P3Z-N-R
284D-FHD2P3D-N-R
284D-FHD2P3B-N-R
1.5
2.0
4.0 A
284D-FHD4P0Z-N-R
284D-FHD4P0D-N-R
284D-FHD4P0B-N-R
2.2
3.0
6.0 A
284D-FHD6P0Z-N-R
284D-FHD6P0D-N-R
284D-FHD6P0B-N-R
3.0
5.0
7.6 A
284D-FHD7P6Z-N-R
284D-FHD7P6D-N-R
284D-FHD7P6B-N-R
240V 50/60 Hz
3-Phase
0.4
0.5
2.3 A
284A-FHB2P3Z-N-R
284A-FHB2P3D-N-R
284A-FHB2P3B-N-R
0.7.5
1.0
4.5 A
284A-FHB4P5Z-N-R
284A-FHB4P5D-N-R
284A-FHB4P5B-N-R
1.5
2.0
7.6 A
284A-FHB7P6Z-N-R
284A-FHB7P6D-N-R
284A-FHB7P6B-N-R
480V 50/60 Hz
3-Phase
0.4
0.5
1.4 A
284A-FHD1P4Z-N-R
284A-FHD1P4D-N-R
284A-FHD1P4B-N-R
0.75
1.0
2.3 A
284A-FHD2P3Z-N-R
284A-FHD2P3D-N-R
284A-FHD2P3B-N-R
1.5
2.0
4.0 A
284A-FHD4P0Z-N-R
284A-FHD4P0D-N-R
284A-FHD4P0B-N-R
2.2
3.0
6.0 A
284A-FHD6P0Z-N-R
284A-FHD6P0D-N-R
284A-FHD6P0B-N-R
3.0
5.0
7.6 A
284A-FHD7P6Z-N-R
284A-FHD7P6D-N-R
284A-FHD7P6B-N-R
Input Voltage
kW
Hp
Output
Current
24 V DC
Control Voltage
120 V AC
Control Voltage
240 V AC
Control Voltage
240V 50/60 Hz
3-Phase
0.4
0.5
2.3 A
284D-SHB2P3Z-N-R
284D-SHB2P3D-N-R
284D-SHB2P3B-N-R
0.7.5
1.0
4.5 A
284D-SHB4P5Z-N-R
284D-SHB4P5D-N-R
284D-SHB4P5B-N-R
1.5
2.0
7.6 A
284D-SHB7P6Z-N-R
284D-SHB7P6D-N-R
284D-SHB7P6B-N-R
480V 50/60 Hz
3-Phase
0.4
0.5
1.4 A
284D-SHD1P4Z-N-R
284D-SHD1P4D-N-R
284D-SHD1P4B-N-R
0.75
1.0
2.3 A
284D-SHD2P3Z-N-R
284D-SHD2P3D-N-R
284D-SHD2P3B-N-R
1.5
2.0
4.0 A
284D-SHD4P0Z-N-R
284D-SHD4P0D-N-R
284D-SHD4P0B-N-R
2.2
3.0
6.0 A
284D-SHD6P0Z-N-R
284D-SHD6P0D-N-R
284D-SHD6P0B-N-R
3.0
5.0
7.6 A
284D-SHD7P6Z-N-R
284D-SHD7P6D-N-R
284D-SHD7P6B-N-R
