D-10 Bulletin 284 CIP Information
Instance 161 is the default input (produced) assembly for the Bulletin
280/281 Distributed Motor Controller
Table D.27 Instance 161 — Default Produced Standard Distributed Motor.
Instance 163 is the standard input (produced) assembly with Network
Outputs for the Bulletin 280/281 Distributed Motor Controller
Table D.28 Instance 163 — Standard Produced Starter with Network
Outputs.
Inverter Type Distributed Motor Controller Input (Produced)
Assemblies
Instance 165 is the default input (produced) assembly for Inverter
Type Distributed Motor Controllers
Table D.29 Default Produced Inverter Type Distributed Motor Controller.
➊ If 284 A is selected.
➋ Refers to output contactor status.
➌ Refers to source brake contactor status.
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 — — — Ready
Running
Rev
Running
Fwd
— Tripped
1 — —
140M
On
HOA
Stat.
User In 3 User In 2 User In 1 User In 0
Reserved
➊
Reserved
➊
Reserved
➊
Reserved
➊
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Ready
Running
Rev
Running
Fwd
Alarm Tripped
1
140M
On
HOA
User In 4 User In 3 User In 2 User In 1
Reserved
➊
Reserved
➊
Reserved
➊
Reserved
➊
2
Net Out
8
Net Out
7
Net Out
6
Net Out
5
Net Out 4 Net Out 3 Net Out 2 Net Out 1
3
Logic
Enable
Stat
Net Out
15
Net Out
14
Net Out
13
Net Out
12
Net Out
11
Net Out
10
Net Out 9
4 ZIP Device Value Key (Low)
5 ZIP Device Value Key (High)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
At
Reference
Net Ref
Status
Net Ctl
Status
Ready
Running
Rev
Running
Fwd
Alarm Tripped
1
Contactor 2
➋
Contactor 1
➌
140M
On
HOA
User In 4 User In 3 User In 2 User In 1
Reserved
➊
Reserved
➊
Reserved
➊
Reserved
➊
2 Output Frequency (Low) (xxx.x Hz)
3 Output Frequency (High) (xxx.x Hz)
