6-34
Bulletin 284 Programmable Parameters for Sensorless Vector Controllers
11
Logic In 1
An input is programmed as Logic In 1 and is active.
12
Logic In 2
An input is programmed as Logic In 2 and is active.
13
Logic In 1 & 2
Both Logic inputs are programmed and active.
14
Logic In 1 or 2
One or both Logic inputs are programmed and one or both is active.
15
StpLogic Out
Drive enters Step Logic step with Digit 3 of Command Word (Parameters 240…247).
16
Timer Out
Timer has reached value set in Parameter 159 (Opto Out 1 Level) or Parameter 162 (Opto Output 2 Level). Use
Parameter 159 or 162 to set threshold.
17
Counter Out
Counter has reached value set in Parameter 159 (Opto Out 1 Level) or Parameter 162 (Opto Output 2 Level). Use
Parameter 159 or 162 to set threshold.
18
Above PF Ang
Power factor angle has exceeded the value set in Parameter 159 (Opto Out 1 Level) or Parameter 162 (Opto
Output 2 Level). Use Parameter 159 or 162 to set threshold.
19
Anlg In Loss
Analog input loss has occurred. Program parameter 122 (Analog In Los) for desired action when loss occurs
20
ParamControl
Enables the output to be controlled over the network communications by writing to Parameter 159 (Opto Out 1
Level) or Parameter 162 (Opto Output 2 Level) (0 = Off, 1 = ON).
21
NonRec Fault
Value set in Parameter 192 (Auto Rstrt Tries) is exceeded.
22
EM Brk Cntrl
EM Brake is energized. Program Parameter 260 (EM Brk Off Delay) and Parameter 262 (EM Brk On Delay) for
desired action.
159 (Opto Out1 Level)
162 (Opto Out2 Level)
Sets the trip point for the digital output relay if the value of Parameter 158 (Opto
Out1 Sel) or Parameter 161 (Opto Out2 Sel) is 6, 7, 8, 10, 16, 17, 18, or 20.
Parameter Number
159 162
Access Rule
GET/SET
Data Type
UINT
Group
Advanced Program Group
Units
—
Minimum Value
0.0
Maximum Value
9999
Default Value
0.0
Options
Description
ATTENTION
!
Parameter 192 (Auto Rstrt Tries) is not enabled. A non-
resettable fault has occurred.
Parameters 158 and 161
Setting
Parameters 159 and 161
Min./Max.
6
0/400 Hz
7
0/180%
8
0/815V
10
0/100%
16
0.1/9999 sec
17
1/9999 counts
18
1/180
°
20
0/1
