Renewal Parts H-13
Figure H.6 Bulletin 284 Base Module Renewal Part Catalog Structure
Base Module Renewal Part
Product Selection Table H.27 Bulletin 284 Base Module Renewal Part, IP67/NEMA 4, Up to 600V
AC With Conduit Entrance
Bulletin
Number
Communications
D
DeviceNet™
A ArmorPoint®
Enclosure Type
F
Type 4 (IP67)
S Type 4X
284 D – F N – 10 – C – Options
Short-Circuit Protection
Bulletin 140 Current Rating (A)
10
10 A Rated Device
25 25 A Rated Device
Option 2 & 3 — Brake Cable Options
SM
Safety monitor
Line Media
C
Conduit
R ArmorConnect™ Power Media
Base
N
Base Only — no starter
Input Voltage kW Hp Output Current Cat. No.
200..240V
50/60 Hz
3-Phase
0.4…0.75 0.5…1.0 2.3 A 280D-FN-10-C
1.5 2.0 7.6 A 280D-FN-25-C
380…480V
50/60 Hz
3-Phase
0.4…2.2 0.5…3.0 1.4…4.0 A 280D-FN-10-C
3.0 5.0 6.0…7.6 A 280D-FN-25-C
460…600V 50/60Hz
3-Phase
0.75…1.5 1.0…2.0 1.7....3.0 A 280D-FN-10-C
2.2...4.0 3.0...5.0 4.2...6.6 A 280D-FN-25-C
200..240V
50/60 Hz
3-Phase
0.4…0.75 0.5…1.0 2.3A 280A-FN-10-C
1.5 2.0 7.6A 280A-FN-25-C
380…480V
50/60 Hz
3-Phase
0.4…2.2 0.5…3.0 1.4…4.0A 280A-FN-10-C
3.0 5.0 6.0…7.6A 280A-FN-25-C
460…600V 50/60Hz
3-Phase
0.75…1.5 1.0…2.0 1.7....3.0A 280A-FN-10-C
2.2...4.0 3.0...5.0 4.2...6.6A 280A-FN-25-C
