Appendix
H
Renewal Parts
Figure H.1 Bulletin 280/281 Control Module Renewal Part Catalog Structure
Control Module Renewal Part Product Selection
Table H.1 Full Voltage Starters — IP67/NEMA Type 4, Up to 575V AC
Table H.2 Full Voltage Starters — NEMA Type 4X, Up to 575V AC
Bulletin Number
280
Full Voltage Starter
281 Reversing Starter
Communications
D
DeviceNet™
A ArmorPoint® ➊
Enclosure Type
F
Type 4 (IP67)
S NEMA Type 4X
24V DC 120V AC 240V AC
12Z 12D 12B
23Z 23D 23B Control Module
N
Control Module Only
Option 1
3
Hand-Off-Auto Selector Keypad
3FR Hand-Off-Auto Selector Keypad
with Forward/Reverse
Motor Connection
R
Round
Overload Selection
Current Range
A 0.24…1.2
B 0.5…2.5 A
C 1.1…5.5 A
D 3.2…16 A
280 D – F 12Z – N B – R – Option 1 – Option 2
Contactor Size/Control Voltage
Option 2
SM
Safety Monitor
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 280D-F12Z-NA-R 280D-F12D-NA-R 280D-F12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 280D-F12Z-NB-R 280D-F12D-NB-R 280D-F12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 280D-F12Z-NC-R 280D-F12D-NC-R 280D-F12B-NC-R
3.2…16 4 7.5 3 5 10 10 280D-F23Z-ND-R 280D-F23D-ND-R 280D-F23B-ND-R
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 280A-F12Z-NA-R 280A-F12D-NA-R 280A-F12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 280A-F12Z-NB-R 280A-F12D-NB-R 280A-F12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 280A-F12Z-NC-R 280A-F12D-NC-R 280A-F12B-NC-R
3.2…16 4 7.5 3 5 10 10 280A-F23Z-ND-R 280A-F23D-ND-R 280A-F23B-ND-R
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 280D-S12Z-NA-R 280D-S12D-NA-R 280D-S12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 280D-S12Z-NB-R 280D-S12D-NB-R 280D-S12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 280D-S12Z-NC-R 280D-S12D-NC-R 280D-S12B-NC-R
3.2…16 4 7.5 3 5 10 10 280D-S23Z-ND-R 280D-S23D-ND-R 280D-S23B-ND-R
➊ Not available with enclosure type “S” (NEMA Type 4X).
