Bulletin 284 Programmable Parameters for Volts per Hertz Controllers 5-39
155 (Relay Out Sel)
Sets the condition that changes the state of the output relay contacts.
See Table 5.C for details
Parameter Number 155
Related Parameters 133, 156, 192
Access Rule GET/SET
Data Type UINT
Group Advanced Program Group
Units —
Minimum Value 0
Maximum Value 21
Default Value 6
Table 5.C Relay Out Sel Options
Options Description
0
Ready/Fault
(Default)
Relay changes state when power is applied. This indicates the drive is ready for operation. Relay returns drive to
shelf state when power is removed or a fault occurs.
1 At Frequency Drive reached commanded frequency.
2 MotorRunning Motor is receiving power from drive.
3 Reverse Drive is commanded to run in reverse direction.
4 Motor Overld Motor overload condition exists.
5 Ramp Reg
Ramp regulator is modifying the programmed accel/decal times to avoid overcurrent or overvoltage fault from
occurring.
6 Above Freq
Drive exceeds the frequency (Hz) value set in Parameter 156 (Relay Out Level) Use Parameter 156 to set
threshold.
7 Above Cur
Drive exceeds the current (% Amps) value set in Parameter 156 (Relay Out Level) Use Parameter 156 to set
threshold.
8 Above DCVolt
Drive exceeds the DC bus voltage value set in Parameter 156 (Relay Out Level). Use Parameter 156 to set
threshold.
9 Retries Exst Value set in Parameter 192 (Auto Rstrt Tries) is exceeded.
10 Above Anlg V Option not valid for Bulletin 284 ArmorStart.
11…19 Not Used Reserved
20 ParamControl
Enables the output to be controlled over the network communications by writing to Parameter 156 (Relay Out
Level) (0 = Off, 1 = ON).
21 NonRec Fault Value set in Parameter 192 (Auto Rstrt Tries) is exceeded.
Relay Out Level
Sets the trip point for the digital output relay if the value of Parameter 155 (Relay
Out Sel) is 6, 7, 8, 10, 16, 17, 18, or 20. Parameter Number 156
Related Parameters 155
Access Rule GET/SET
Data Type UINT
Group Advanced Program Group
Units 0.1
Minimum Value 0.0
Maximum Value 9999
Default Value 2.0
Parameter 155 Setting Parameter 156 Min./Max.
6 0/400 Hz
7 0/180%
8 0/815V
10 0/100%
20 0/1
