B-22 Bulletin 280/281 CIP Information
The following common services are implemented for the Parameter
Object:
Table B.42 Parameter Object Common Services
Parameter Group Object — CLASS
CODE 0x0010 The following class attributes are supported for the Parameter Object:
Table B.43 Parameter Group Object Class Attributes
All Bulletin 280/281 Motor Starters have the following instances of
the parameter group object:
• Instance 1 = DeviceLogix Parameters
• Instance 2 = DeviceNet Parameters
• Instance 3 = Starter Protection Parameters
• Instance 4 = User I/O Parameters
• Instance 5 = Miscellaneous Setup Parameters
• Instance 6 = ZIP Parameters
• Instance 7 = Starter Display
• Instance 8 = Starter Setup
The following instance attributes are supported for all parameter
group instances:
Table B.44 Parameter Group Object Instance Attributes
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x01 No Yes Get_Attributes_All
Attribute ID Access Rule Name Data Type
1 Get Revision UINT
2 Get Max Instance UINT
Attribute ID Access Rule Name Data Type
1 Get Group Name String SHORT_STRING
2 Get Number of Members UINT
3 Get 1
st
Parameter UINT
4 Get 2
nd
Parameter UINT
n Get Nth Parameter UINT
