H-2 Renewal Parts
Bulletin 280/281, Continued Table H.3 Reversing Starters — IP67/NEMA Type 4, Up to 575V AC
Table H.4 Reversing Starters — NEMA Type 4X, Up to 575V AC
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 281D-F12Z-NA-R 281D-F12D-NA-R 281D-F12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 281D-F12Z-NB-R 281D-F12D-NB-R 281D-F12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 281D-F12Z-NC-R 281D-F12D-NC-R 281D-F12B-NC-R
3.2…16 4 7.5 3 5 10 10 281D-F23Z-ND-R 281D-F23D-ND-R 281D-F23B-ND-R
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 281A-F12Z-NA-R 281A-F12D-NA-R 281A-F12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 281A-F12Z-NB-R 281A-F12D-NB-R 281A-F12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 281A-F12Z-NC-R 281A-F12D-NC-R 281A-F12B-NC-R
3.2…16 4 7.5 3 5 10 10 281A-F23Z-ND-R 281A-F23D-ND-R 281A-F23B-ND-R
Current
Rating (A)
kW Hp Cat. No.
230V AC
50 Hz
400V AC
50 Hz
200V AC
60 Hz
230V AC
60 Hz
460V AC
60 Hz
575V AC
60 Hz
24V DC 120V AC 240V AC
0.24…1.2 0.18 0.37 — — 0.5 0.5 281D-S12Z-NA-R 281D-S12D-NA-R 281D-S12B-NA-R
0.5…2.5 0.37 0.75 0.5 0.5 1 1.5 281D-S12Z-NB-R 281D-S12D-NB-R 281D-S12B-NB-R
1.1…5.5 1.1 2.2 1 1 3 3 281D-S12Z-NC-R 281D-S12D-NC-R 281D-S12B-NC-R
3.2…16 4 7.5 3 5 10 10 281D-S23Z-ND-R 281D-S23D-ND-R 281D-S23B-ND-R
