C-6 Bulletin 283 CIP Information
Table C.10 DeviceNet Assembly Object Instance Attributes
➊ Not available on the Bulletin 283A.
Custom Parameter Based
“Word-wise” I/O Assemblies
Table C.11 Custom Parameter Based “Word-Wise” (Produced) Assembly
Instance 120
“Word-wise” Bit-Packed
Assemblies Assemblies whose instance numbers are 180…189 are all one word
(16 bits) long. They can be used “stand alone”, but their main use is to
assemble information for EDS file parameters. These “word-wise”
assemblies become the building blocks for the custom
parameter-based “word-wise” assemblies described above. Note that
these “word-wise” assemblies are designed for use with
DeviceLogix™, so their contents reflect the various words in the
DeviceLogix data table.
Attribute ID Type Description
3 Consumed Required ODVA Consumed Instance
52 Produced Required ODVA Produced Instance
120 Produced Custom Parameter Based Word Wise Assembly
160 Consumed Default Consumed Instance for DOL and SoftStart units
161 Produced Default Produced Instance for DOL and SoftStart units
162 Consumed
Standard Consumed Instance for DOL and SoftStart with
Network Inputs
163 Produced
Standard Produced Instance for DOL and SoftStart with
Network Outputs
172 Consumed SMC Dialog Native Consumed
173 Produced SMC Dialog Native Produced
181 Produced User Inputs ➊
182 Consumed Consumed Network Bits (a.k.a Network Inputs)
183 Produced Produced Network Bits (a.k.a. Network Outputs)
184 Produced Trip Status Bits
185 Produced Starter Status Bits
186 Produced DeviceNet Status Bits
187 Consumed Starter Control Bits
189 Produced Warning Status Bits
190 Produced 1799-ZCIO Bits
Instance 120
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
0 Value of the parameter pointed to by “Prod Assy Word 0” Param (low byte)
1 Value of the parameter pointed to by “Prod Assy Word 0” Param (high byte)
1
2 Value of the parameter pointed to by “Prod Assy Word 1” Param (low byte)
3 Value of the parameter pointed to by “Prod Assy Word 1” Param (high byte)
2
4 Value of the parameter pointed to by “Prod Assy Word 2” Param (low byte)
5 Value of the parameter pointed to by “Prod Assy Word 2” Param (high byte)
3
6 Value of the parameter pointed to by “Prod Assy Word 3” Param (low byte)
7 Value of the parameter pointed to by “Prod Assy Word 3” Param (high byte)
