Specifications A-5
Bulletin 283
Electrical Ratings UL/NEMA IEC
Power Circuit Rated Operation Voltage 200V…575V 200…600V
Rate Insulation Voltage 600V 500V
Rated Impulsed Voltage 6 kV 6 kV
Dielectric Withstand 2200V AC 2500V AC
Operating Frequency 50/60 Hz 50/60 Hz
Utilization Category N/A AC-3
Protection Against Shock N/A IP2X
Rated Operating Current Max. 3.0 A / 5.5 A / 7.6 A / 16 A
Short Circuit
Protection
SCPD performance Type 1
Current Rating Voltage 480Y/277V 480/480V 600Y/347V 600V
1.1…3.0 A
Sym. Amps
RMS
65 kA 65 kA 30 kA 30 kA 3.0…5.5 A
5.3…7.6 A
6.3…16 A 30 kA 30 kA 30 kA 30 kA
SCPD List Size per NEC Group Motor —
Control Circuit
Rated Operation Voltage
24V DC (+10%, -15%) A2 (should be grounded at voltage source)
120V AC (+10%, -15%) A2 (should be grounded at voltage source)
240V AC (+10%, -15%) A2 (should be grounded at voltage source)
Rate Insulation Voltage 250V 250V
Rated Impulsed Voltage — 4 kV
Dielectric Withstand 1500V AC 2000V AC
Overvoltage Category — III
Operating Frequency 50/60 Hz 50/60 Hz
Power Requirements
Units
Control Voltage (Nom) Volts 24V DC 120V AC 240V AC
Power Supply (Nom) Amps 0.170 0.110 0.060
Total Control Power (Starting/Stopping) VA (W) (90.0 W) 35 35
Total Control Power (Running) VA (W) (8.0 W) 28 28
External Devices powered by Control Voltage
Outputs (2) 1 A max. each) Amps 2 2 2
Total Control (Starting/Stopping) with max. outputs VA (W) (138.0 W) 275 515
Total Control (Running) with max. outputs VA (W) (56.0 W) 268 508
Input Ratings Rated Operation Voltage 24V DC
Input On-State Voltage Range 10…26V DC
Input On-state Current
3.0 mA @ 10V DC
7.2 mA @ 24V DC
Input Off-state Voltage Range 0…5V DC
Input Off-state Current <1.5 mA
Input Filter — Software Selectable
Off to On Settable from 0…64 ms in 1 ms increments
On to Off Settable from 0…64 ms in 1 ms increments
Input Compatibility N/A IEC 1+
Number of inputs 4
Sensor Source
Voltage Status Only 11…25V DC from DeviceNet™
Current Available 50 mA MAX per Input, 200 mA Total
Output Ratings (Sourced
from Control Circuit) Rated Operation Voltage 240V AC / 30V DC 240V AC / 30V DC
Rate Insulation Voltage 250V 250V
Dielectric Withstand 1500V AC 2000V AC
Operating Frequency 50/60 Hz 50/60 Hz
Type of control circuit Electromechanical Relay
Kind of Current AC/DC
Conventional Thermal Current I
th Total of both outputs ≤ 2 A
Type of Contacts Normally Open (N.O.)
Number of Contacts 2
ArmorPoint® Ratings Backplane Current Load 400 mA
