Appendix
A
Specifications
Bulletin 280/281
Electrical Ratings UL/NEMA IEC
Power Circuit Rated Operation Voltage 200V…575V 200…575V
Rate Insulation Voltage 600V 600 V
Rated Impulsed Voltage 6 kV 6 kV
Dielectric Withstand 2200V AC 2500V AC
Operating Frequency 50/60 Hz 50/60 Hz
Utilization Category N/A AC-3
Protection Against Shock N/A IP2X
Rated Operating Current Max.
1.2 A
2.5 A
5.5 A
16 A
Control
Circuit
Rated Operation Voltage
24V DC (+10%, -15%) A2 (should be grounded at voltage source)
120V AC (+10%, -15%) A2 (should be grounded at voltage source)
240V AC (+10%, -15%) A2 (should be grounded at voltage source)
Rate Insulation Voltage 250V 250V
Rated Impulsed Voltage — 4 kV
Dielectric Withstand 1500V AC 2000V AC
Overvoltage Category — III
Operating Frequency 50/60 Hz 50/60 Hz
Short Circuit
Protection
SCPD Performance Type 1
Current Rating Voltage 480Y/277V 480 V 600Y/347 V 600 V
0.24…1.2 A
Sym. Amps RMS
65kA 65kA 30kA 30kA 0.5…2.5 A
1.1…5.5 A
3.2…16 A 30kA 30kA 30kA 30kA
SCPD List Size per NEC Group Motor —
Power Requirements
Units W/O HOA W/ HOA
Control Voltage Volts 24V DC 120V AC 240V AC 24V DC 120V AC 240V AC
Contactor (Pick Up) Amps 0.71 0.583 0.292 0.71 0.583 0.292
Contactor (Hold In) Amps 0.63 0.075 0.038 0.063 0.075 0.038
Total Control Power (Pick Up) VA (W) (17.0 W) 70 70 (21.0 W) 83 84
Total Control Power (Hold In) VA (W) (1.5 W) 9 9 (5.6 W) 22 23
External Devices powered by Control Voltage
Outputs (2) 1 A max. each) Amps 2 2 2 2 2 2
Total Control (Pick Up) with
max. outputs
VA (W) (65.0 W) 310 550 (73.0 W) 336 579
Total Control (Hold In) with
max. outputs
VA (W) (50.0 W) 249 489 (58.0 W) 275 518
Input Ratings Rated Operation Voltage 24V DC
Input On-State Voltage Range 10…26V DC
Input On-state Current
3.0 mA @ 10V DC
7.2 mA @ 24V DC
Input Off-state Voltage Range 0…5V DC
Input Off-state Current <1.5 mA
Input Filter — Software Selectable
Off to On Settable from 0…64 ms in 1 ms increments
On to Off Settable from 0…64 ms in 1 ms increments
Input Compatibility N/A IEC 1+
Number of inputs 4
Sensor Source
Voltage Status Only 11…25V DC from DeviceNet™
Current Available 50 mA MAX per Input, 200 mA Total
Output Ratings (Sourced
from Control Circuit) Rated Operation Voltage 240V AC / 30V DC 240V AC / 30V DC
Rate Insulation Voltage 250V 250V
Backplane Current Load 400 mA
50/60 Hz 50/60 Hz
Type of control circuit Electromechanical Relay
Kind of Current AC/DC
Conventional Thermal Current I
th Total of both outputs ≤ 2 A
Type of Contacts Normally Open (N.O.)
Number of Contacts 2
ArmorPoint® Ratings Backplane Current Load 400 mA
