Appendix
D
Bulletin 284 CIP Information
Electronic Data Sheets Electronic Data Sheets (EDS) files are specially formatted ASCII
files that provide all of the information necessary for a configuration
tool (e.g., RSNetWorx
™
for DeviceNet™ Revision 3.21 Service Pack
2 or later) to access and alter parameters of the device. The EDS file
contains all of the device information: number of parameter,
groupings, parameter name, minimum, maximum, and default values,
units, data format, and scaling.
EDS files for all the ArmorStart® Distributed Motor Controllers units
are available from the Internet at www.ab.com/networks/eds.
They may also be built automatically by some configuration tools
since much of the information necessary for an EDS file may be
extracted from the ArmorStart Distributed Motor Controller.
VFD Type Product Codes and Name
Strings Product codes for the Bulletin 284 variable frequency drives are based
on the Horse Power Rating and Supply Voltage rating of the
Distributed Motor Controller. Table D.1 lists the product codes and
name strings for the Bulletin 284 Distributed Motor Controllers:
Table D.1 Bulletin 284 Product Codes and Name Strings
284A
Device
Type ➊
284D
Device
Type ➋
Product
Code
Hp Supply Voltage Name String Drive Type
133 22 0x132 0.50 240V AC ArmorStart 284D PF4 240V 0.5 Hp PF4
133 22 0x134 1 240V AC ArmorStart 284D PF4 240V 1 Hp PF4
133 22 0x136 2 240V AC ArmorStart 284D PF4 240V 2 Hp PF4
133 22 0x142 0.50 480V AC ArmorStart 284D PF4 480V 0.5 Hp PF4
133 22 0x144 1 480V AC ArmorStart 284D PF4 480V 1 Hp PF4
133 22 0x146 2 480V AC ArmorStart 284D PF4 480V 2 Hp PF4
133 22 0x147 3 480V AC ArmorStart 284D PF4 480V 3 Hp PF4
133 22 0x148 5 480V AC ArmorStart 284D PF4 480V 5 Hp PF4
133 22 0x1B2 0.50 240V AC ArmorStart 284D PF40 240V 0.5 Hp PF40
133 22 0x1B4 1 240V AC ArmorStart 284D PF40 240V 1 Hp PF40
133 22 0x1B6 2 240V AC ArmorStart 284D PF40 240V 2 Hp PF40
133 22 0x1C2 0.50 480V AC ArmorStart 284D PF40 480V 0.5 Hp PF40
133 22 0x1C4 1 480V AC ArmorStart 284D PF40 480V 1 Hp PF40
133 22 0x1C6 2 480V AC ArmorStart 284D PF40 480V 2 Hp PF40
133 22 0x1C7 3 480V AC ArmorStart 284D PF40 480V 3 Hp PF40
133 22 0x1C8 5 480V AC ArmorStart 284D PF40 480V 5 Hp PF40
133 22 0x1D4 1 600V AC ArmorStart 284D PF40 600V 1 Hp PF40
133 22 0x1D6 2 600V AC ArmorStart 284D PF40 600V 2 Hp PF40
133 22 0x1D7 3 600V AC ArmorStart 284D PF40 600V 3 Hp PF40
133 22 0x1D8 4 600V AC ArmorStart 284D PF40 600V 5 Hp PF40
➊133= PointBus Motor Starter
➋ 22= Motor Starter
